CNC Horizontal Machining

Wiscon uses CNC Horizontal Machining to produce manifolds, valve housings, and distribution blocks. These parts are then used by automotive, heavy construction, and agricultural equipment manufacturers. The horizontal machining process allows for metal scraps to fall away as the parts are machined and passed through. Our ISO certificate leads to an extensive quality assurance process to assure our clients that each CNC product will meet their exact specifications.

Kitamura HX400G Horizontal Machining Center

  • 16 Cubic Inches
  • 4-Axis
  • 12,000 RPM
  • Up to 30 HP Horizontals & Verticals
  • 100 Tools
  • High Pressure Three-Tool Coolant
  • 1,180 IPM
  • High-Speed Pallet Shuttles

SMART SX 4000 Horizontal Machining Center

  • X Travel = 22.05
  • Y Travel = 22.05
  • Z Travel = 27.17
  • Table Size = 15.75
  • Spindle Taper = #40
  • Spindle Speed = 100-15,000 RPM
  • Spindle HP = 50
  • Spindle Torque = 184 Ft/Lbs
  • Rapid Traverse Rate = 2,480
  • Number of Tools = 60
